Demand for pet X-ray machines has been increasing. The ability to diagnose various diseases and injuries through X-ray imaging is an important aspect of modern pet care. Pet X-ray machines allow veterinarians to diagnose diseases such as pneumonia, cancer and heart disease in pets. In addition, fractures, joint problems and other injuries in pets can be diagnosed more quickly and accurately using X-ray imaging.
Analog Horse/Cat/Dog X Ray Machine Veterinary Digital Radiography Features:
1. Designed for animal photography, easy to operate.
2. Compact structure design, excellent coverage performance, support the whole body multi-angle photography.
3. The four-way floating bed surface can be moved back and forth and left and right, which is more convenient for taking pictures of pet limbs and other parts.
4. Professional animal image acquisition software, with animal graphics as the main parameter setting and remote exposure control mode.
5. There are multiple filming programs, users can modify and save by themselves.
6. The X-ray tube head can be rotated ±180° around the center of the support arm, which is convenient for doctors to take Angle position, lateral position and special Angle photos of animals.
7. After power failure, the system automatically saves the parameters to ensure that the parameters are not lost.
Model | VET1700-D20 | VET1700-D20 | VET1700-D32 | |
X-ray Generator | Output Power | 20kW | 32kW | 32kW |
Power Voltage | 220V±22V | |||
kV range | 40~120kV | 40~125kV | ||
mA range | 32~200mA | 32~320mA | 32~400mA | |
mAs range | 0.32 ~200mAs | 0.32 ~200mAs | 0.32 ~400mAs | |
Loading time | 10~4000ms | 10~5000ms | 10~5000ms | |
X-ray Tube | Small focus | 1 | ||
Large focus | 2 | |||
Anode speed | 2800r/min |
