YX932D Plus Pneumatic Foot Pedal Suction Machine Mobile Suction Apparatus YX932D Plus Pneumatic Foot Pedal Suction Machine Mobile Suction Apparatus

Most medical aspirators are portable and mobile (with moving parts) to deal with any emergency if needed. Therefore, its flexible use makes it play a vital role in the medical field.

Quantity:
Share this:
  • Product Description
  • Parameter

Pneumatic Foot Pedal Suction Machine Mobile Suction Apparatus Description:

The foot pedal suction machine became one of the indispensable devices in medical institutions with its efficient clearance function, portability, safety and advantages in multiple application fields. mobile suction apparatus can quickly and effectively remove secretions and foreign objects in the body cavity and airway, ensuring the patient's airway is clear.

Pneumatic Foot Pedal Suction Machine Mobile Suction Apparatus Features:

Electric suction device is a mobile medical suction device with high negative pressure and high flow. The product is used in medical institutions for suction of secretions in the airway of patients and for exudation and flushing fluid of patients during operation. The product is not suitable for abortion attraction.

foot pedal suction machine, suction machine, mobile suction apparatus

1. Large flow oil-free vacuum pump as a negative pressure source, negative pressure rises quickly, will not produce positive pressure.

2. The operation and suction pressure of the machine can be adjusted through the pneumatic foot switch.

3. Large capacity PC liquid storage bottle easy to clean, optional glass bottle

4. Hydrophobic air filter and overflow protection device form double protection to prevent liquid from entering the intermediate pipe.

5. The negative pressure regulating valve can be adjusted according to the clinical stepless, and the vacuum gauge shows the negative pressure value.

6. Push and pull handles and casters to achieve flexible movement.



Specification
ModelYX932D Plus
Max vacuum≥0.09 MPa(680mmHG)
Adjustable Vacumm Range0.02MPa(150mmHG)~Max.Vacuum
Noise≤65dB(A)
Flow Rate≥32L/min
PowerAC 220V,50Hz
Input power(VA)180 VA
Storage bottlePC Bottle:2000ml×2
(Optional Glass bottle)
N.W.:12.5Kg
G.W.:15Kg
Package Size45cm×52cm×58cm
×
