Main Usage: Electric operating table can be operated for clinical use.
Structure :Operating table consists of two parts: mechanical and electro-hydraulic control system. Depending on manual operation, the product can meet the requirement of posture in clinical operation.
Neurosurgery Operating Table With Swivel Tabletop Description:
Neurosurgery operating tables are suitable for various operation tables conducted by the medical unit. Various actions are controlled by a hydraulic Pneumatic system. The operating table of 180° rotation helps every surgical requirement. The size of the bed is ergonomic and can easily adjust various positions such as cervical vertebra, lumbar vertebra and spine. The operating table has complete functions and excellent performance. It is an ideal surgical instrument.
Main Usage: The operating table can be operated for clinical use.
Neurosurgery Operating Table With Swivel Tabletop Features:
General features:
1. The bed is composed of five movable sections: head plate, back plate, waist plate (selected for timing), seat plate and leg plate;
2. The appearance of the stainless steel round cover and base is nice and elegant. The cover is dust-proof and water-proof. The main material is stainless steel, high-intensity cast iron, aluminum, good solidity.
3. High density sponge is made of artificial leather or polyurethane as a whole, with antistatic properties.
4. There are four casters on the bottom of the operating table. The operation bed is easy to move, and the pedal brake function can make the bed stand stable.
5. Equipped with a miniature hand controller, which can control various preset actions of each section by touch.
6. They can safely support more than 150 kilograms, depending on the operation.
Electrical characteristics:
1. Emergency power supply is Optional. Emergency power supply is made of lead-acid batteries, which can be automatically charged. Emergency power supply can start to work automatically when the power is off.
Technical Features:
1. The operating table is composed of mechanical and electro-hydraulic control system.
2.The operating table uses electro-hydraulic systems to control all the movements: height adjustment, trendelenburg and reversed trendelenburg, lateral tilt, back movements, forward and backward movement and brake. Head section, leg section and vertical rotation of tabletop are operated by manual operation.
3. The head and tail plate surface adopts unique imported air spring (Imported from Germany), flexible operation.
3. Electrically controlled brake can firmly fix the bed.
4. The forward and backward movement 250mm and 180 °rotation of tabletop can make C-ARM perspective quick and easy.
5. Optional one-key horizontal restoration, which can be restored to the original state by one key at any position.
6. Optional waist bridge
Main Parameter | |
Model | AOT402 |
Operating Table Size | |
Length | 2050mm |
Width | 500mm |
Dimension of section: | |
Head Section | 250×500mm |
Back Section | 465×500mm |
Waist Section | 75×500mm |
Seat section | 550×500mm |
Leg Section | 600×240mm |
Table Overall Adjustable Range | |
Min. height of table top from floor | 580mm |
Max. height of table top from floor | 930mm |
Tendelenburg | ≥20º |
Reversed tendelenburg | ≥15º |
Lateral tilt | ≥15º |
Backward and forward movements | 250mm |
Horizonal ratation of tabletop | 0~180° |
Table Section Adjustment Range | |
Head section raised from the horizontal | ≥45º |
Head section lowered from the horizontal | ≥90º |
Kidney bridge elevated(Optional) | 80mm |
Back section raised from the horizontal | ≥75º |
Back section lowered from the horizontal | ≥30º |
Leg section lowered from the horizontal | ≥90º |
Foot board can be horizontal or vertical with leg board. | |
Power Supply | AC 220V±10%,50Hz |
Basic Accessories: | Anaesthetic screen: 1 set |
Arm support: 1 pair | |
Body support: 1 pair | |
leg support: 1 pair | |
Cushion: 1 set |
