USMSU3 Full Digital Animal Diagnostic Ultrasound Mini Portable Handheld Vet Ultrasound Machine

USMSU3 Full Digital Animal Diagnostic Ultrasound Mini Portable Handheld Vet Ultrasound Machine USMSU3 Full Digital Animal Diagnostic Ultrasound Mini Portable Handheld Vet Ultrasound Machine

Industry-leading veterinary ultrasound machines for equine, large animal, small animal, zoo mammal, and marine mammal medicine. These ultrasounds provide a huge value and bring portable diagnostic ultrasound imaging within reach of every veterinary professional.

Quantity:
Share this:
  • Product Description
  • Parameter

Domestic and foreign standard configuration

Main unit: 1 pc
3.5MHz waterproof mechanical sector probe : 1 pc.
Power adapter: 1 pc
Internal battery : 1pc
Power line : 1 pc
Shutter line : 1 pc
Straps : 1 pc
Instrument backpack : 1 pc
OTG U disk : 1 pc

Product parameters:

Using the latest cortex-m4 embedded control system + miniaturized exclusive ultrasound technology hardware system; MSU3 has triple function of A scan, B scan and ear tag scan, the perfect solution to the various needs of users;
3.5" high resolution color LCD, small size, light weight and portable,suitable for outdoor use;
Menu interface operation, Language: Chinese/English switchable;
Gray:256
Display mode:B, 2B, A, total 3 kinds.
B mode and A mode gain range: 27 ~ 90dB
Near field gain: -31 ~ 0dB;
Far Field Gain: 0 ~ 31dB;
Dynamic range:27~90dB
3 kinds of depth range, 126,163,200, the maximum display depth of 200mm;
Compression curve adjustment: 4 kinds, from 0 to 3;
Frequency: 2.5M, 3.5M;
Frame correlation: 0 ~ 5,6 kinds;
Pseudo-color function: 0 ~ 7,8 species (including black and white);
Able to measure backfat thickness, muscle thickness and lean percentage;
Image Storage: image or measurement data stored in the U disk;
Scale of the image display: 3 kinds, "0" is not displayed ruler, "1" is displayed 10mm pitch of dot scale, "2" is displayed vertical and horizontal pitch of 10mm dot scale;
Supports 3 kinds ear tag format: EM4305, EM4100, T5557;
Unique ear tag scanning function: ear tag scanning within a set time (10-30 seconds) to complete the ear tag scanning;
B scan and A scan measured data can be stored in Excel table, user-friendly data management, processing all kinds of information;
Unique menu display settings: Menu disappears automatically at a set time, user-friendly observation image;
Screen saver function;
System settings probe guard time, automatically freeze, protect probe;
Support multiple languages: Chinese, English, French, German, Spanish, Portuguese;
Dual power supply. Power: 100-240V ~ ± 10% 1.2-0.6A Frequency: 50-60Hz ± 1Hz;
Battery Configuration: Large capacity (2600mAh) lithium battery can support more than 300 minutes work;
Net Weight: 620g;
Main unit size:90×98×25mm(length x width x height)

×
