Flexible assembly, free combination. The modular design can realize any combination of infusion pump and injection pump. Easily extend multiple channels without any tools. It is an intelligent, efficient and safe digital infusion workstation.
Multi-Syringe/Infusion Infusion Pump Docking Station Features：
Workstation:
1. The new stacked design brings maximum combination flexibility for a variety of infusion scenarios
2. The syringe and infusion pump can be combined in the same workstation for the convenience of doctors and nurses.
3. 5ml, 10ml, 20ml, 30ml, 50ml, 60ml syringes can be used, compatible with any standard infusion pump.
4. Smart alarm systems provide more obvious indications.
5. 3.5-inch touch screen with real-time monitoring, data review, alarm recording and drug management functions.
6. Accurate infusion speed provides high precision and consistent performance for long-term infusion.
7. Multiple data ports, including USB ports, nurse call ports, and network cable ports
1. All medical pumps support cascade function and can be combined with bedside infusion workstation to form bedside infusion management system
2. 3.5 "large full-color LCD screen, easy to use
3. The bottom of each pump is designed with slots, which can be stacked with multiple pumps to save space and meet clinical needs
4. Equipped with intelligent large-capacity lithium battery, battery life up to 10 hours, and real-time detection of power
5. Support WiFi transmission, wireless networking to the central workstation and hospital electronic information system
6. Can be hung and lifted, flexible transfer, and transfer process can be transmitted through WIFI
7. Independent multi-CPU control: multi-channel independent sound and light alarm to ensure safe infusion
8. Support the function of drug library and DERS intelligent drug protection system to ensure the drug safety of patients
9. Built-in data storage, data storage ≥10000, more than 8 years of memory storage, review treatment history at any time
Infusion pump:
1. It has eight working modes, including speed, trace, time, weight, gradient, sequence, first dose and number of drops, which is closer to clinical application
2. It can be connected with external drop number sensor to realize closed-loop accurate infusion
Injection pump:
1. It has seven operating modes, including speed, trace, time, weight, gradient, sequence and first dose, which is closer to clinical application
| Model | WRIP-9021N |
| Applicable Pump | Infusion Pump，Syringe Pump |
| Alarms | Same as syringe pump and infusion pump |
| Features | Self-checking, LCD display, automatic power switching, mute key,system memory, key locker, night mode |
| Data Interface | Wi-Fi, wired, USB, nurse call, drop sensor |
| Drug Library | Available |
| Occlusion Sensitivity | 12 levels (20-130 kPa, in 10 kPa increments) |
| Occlusion Unit | kPa, mmHg, psi, bar |
| History Log | 10,000 events |
| Alarm Volume | 8 levels |
| Auto. multi-channel relay | Available |
| Power Supply, AC | AC100-220V 50/60Hz |
| Battery | DC7.2V, rechargeable |
| Battery Life | 4 hours |
| Working Temperature | 10-40°C |
| Relative Humidity | 30-75% |
| Atmospheric Pressure | 760-1060 hpa |
| Size | 300*200*300mm |
| Weight | 2.8 kg |
| Waterproof | IPX3 |
| Safety Classification | Class II |
| Model | WRIP-6061N |
| Syringe Size | 5, 10, 20, 30, 50/60 mL |
| Applicable Syringe | Compatible with syringe of any standard |
| VTBI | 0.1-99999.99 mL (in 0.01 mL increments) |
| Infused Volume | 0-99999.99 mL (in 0.01 mL increments) |
| Infused Volume | Syringe 5 ml: 0.1-100 ml/h Syringe 10 ml: 0.1-300 ml/h Syringe 20 ml: 0.1-600 ml/h Syringe 30 ml: 0.1-800 ml/h Syringe 50/60 ml: 0.1-1500 ml/h 0.1-99.99 mL/h in 0.01 m/h increments 100-999.9 mL/h in 0.1 m/h increments 1000-1500 mL/h in 1 ml/h increments |
| Bolus Rate(Manual, Auto) | 50 m/h-1500 m/h (in 0.01, 0.1, 1 mL increments) |
| Bolus Volume | 0.1-50 mL (in 0.1 mL increments) |
| Anti-Bolus | Automatic |
| Accuracy | ±2% (mechanical accuracy≤1%) |
| Infusion Mode | Rate mode, micro mode, time mode, body weight, initial dose mode,sequential mode, ramp up/down mode, drop mode |
| KVO Rate | 0.1-10 mL/h (in 0.1 mL/h increments) |
| Infusion Mode | Occlusion, near empty, end program, low battery, end battery,no battery, AC power off, motor malfunction, system malfunction,standby, syringe installation error, syringe drop off |
| Additional Features | Automatic power switching, automatic syringe identification,mute key, purge, bolus, anti-bolus, system memory, key locker,change flow rate without stopping the pump |
| Drug Library | Available |
| Occlusion Sensitivity | High, medium, low |
| Docking Station | Stackable up to 4-in-1 or 6-in-1 Docking Station with single power cord |
| Occlusion Sensitivity | 12 levels (20-130 kPa, in 10 kPa increments) |
| Occlusion Unit | kPa, mmHg, psi, bar |
| History Log | 100,000 events |
| Alarm Volume | 8 levels |
| Auto. multi-channel relay | Available |
| Power Supply, AC | AC100-240V 50/60Hz |
| Battery | DC14.4V, rechargeable |
| Battery Life | 10 hours at 5 ml/h |
| Working Temperature | 5-40°C |
| Relative Humidity | 15-80% |
| Atmospheric Pressure | 860-1060 hpa |
| Size | 860-1060 hpa |
| Weight | 2.5 kg |
| Waterproof | IPX3 |
| Safety Classification | Class II , type CF |
| Model | WRIP-8081N |
| Pumping Mechanism | Curvilinear peristaltic |
| IV Set | Compatible with IV sets of any standard |
| Flow Rate | 0.1-2000 mL/h (in 0.01, 0.1, 1 mL /h increments) |
| Bolus Rate (Manual, Auto) | 50-1500 mL/h (in 0.01, 0.1, 1 mL/h increments) |
| Bolus Volume | 0.1-50 mL (in 0.01 mL increments) |
| Accuracy | ±3% |
| VTBI | 0.1-99999.99 mL (in 0.01 mL increments) |
| Infused Volume | 0-99999.99 mL (in 0.01 mL increments) |
| Infusion Mode | Rate mode, micro mode, time mode, body weight, initial dose mode,sequential mode, ramp up/down mode, drop mode |
| KVO Rate | 0.1-10 mL/h (in 0.1 mL/h increments) |
| Alarms | Occlusion, air-in-line, door open, near end, end program,low battery, end battery, AC power off, motor malfu unction,system malfunction, standby, drop error |
| Additional Features | Automatic power switching, mute key, purge, bolus, system memory,key locker, change flow rate without stopping the pump |
| Drug Library | Available |
| Occlusion Sensitivity | 12 levels (20-130 kPa, in 10 kPa increments) |
| Occlusion Unit | kPa, mmHg, psi, bar |
| History Log | 100,000 events |
| Air-in-line Detection | Ultrasonic detector 40-800 μL (in 20 μL increments) |
| Double Bubble Sensor | Available |
| Alarm Volume | 8 levels |
| Auto. multi-channel relay | Available |
| Drop Sensor | Optional |
| Power Supply, AC | AC100-240V 50/60Hz |
| Battery | DC14.4V, rechargeable |
| Battery Life | 10 hours at 25 ml/h |
| Working Temperature | 5-40°C |
| Relative Humidity | 15-80% |
| Atmospheric Pressure | 860-1060 hpa |
| Size | 240*176*87 mm |
| Weight | 2.5 kg |
| Waterproof | IPX3 |
| Safety Classification | Class II, type CF |
