US350 Hospital Portable Trolley Full Digital 3D BW Ultrasound Scanner
US350 Hospital Portable Trolley Full Digital 3D BW Ultrasound Scanner

US350 Hospital Portable Trolley Full Digital 3D BW Ultrasound Scanner US350 Hospital Portable Trolley Full Digital 3D BW Ultrasound Scanner

The ultrasound machine is completely portable yet it offers the same features and quality of a much larger system. It’s perfect for private practices, clinics and hospitals. It’s easy to use and it is about half the size of traditional console-based systems, which means you can take it just about anywhere.

Quantity:
Share this:
  • Product Description
  • Parameter

US350 Full Digital 3D BW Ultrasound Scanner Features:

Full digital image formation technology

Advanced all dynamic focusing

USB port: storable and readable

High-accuracy DSC digital scan conversion

Humanized ABS injection mould, unibody chassis

Intelligentized 8-segment TGC adjustment

Progressive SMT components technology

Unique 4B imaging modes

Reliable backlit, silica gel keyboard, photoelectric-tracking control

Standard Configuration:

14 inch CRT high resolution display

3.5MHz Multi-frequency convex probe(2.5MHz-4.5MHz)

Options:

7.5MHz Multi-frequency high frequency linear probe(6.5MHz-8.5MHz)6.5MHz Multi-frequency Trans-vaginal probe(5.5MHz-7.5MHz)

7.5MHz Multi-frequency Trans-rectal probe(6.5MHz-8.5MHz)

US350 Hospital  Trolley Full Digital 3D BW Ultrasound Scanner.jpg

Specification:

Scanning mode: convex / linear / micro-convex

Probes: 96 elements convex probe,trans-vaginal probe, trans-rectal probe, high frequency linear probe

Monitor: 14 inch high resolution CRT

Operation panel: user-friendly, convenient and flexible with back-lit silica gel keyboard & track ball operation

Display mode: B, B+B, B+M, M, 4B

Detecting depth: ≥242mm

Resolution: lateral≤2mm, axial≤1mm

Blind Zone: ≤3mm

Geometry precision: lateral≤5%, axial≤5%

Gray scale: 256

Electronical focusing: 2 focuses combination randomly

Cine loop: 256 frames, realized in automatic successive playback and manual single step forward, backward playback

USB port: storable and readable

Image storage: 8

Local zoom can be used at real time.

Magnification: ×0.8, ×0.8, ×0.90, ×0.95, ×1.0, ×1.05, ×1.10, ×1.20, ×1.30, ×1.40, ×1.50, ×1.60, ×1.80, ×2.0, ×2.2, ×2.5.(16 kinds)

Body marks: 30

Probe interface: 2

Pseudo color: 7

Image processing,: up/ down, left / right, black / white convertion, edge enhancement, gamma correction, frame correlation, pseudo color processor( need external color display).

Measurement: distance, perimeter, area, volume, heart rate, gestational week, FW, AFI, EDD , maternity table,  heart package etc.

Note: date, time, name, sex, age, doctor, hospital, comment, Chinese/ English conversion.

Output interface: PAL-D, SVGA (SVGA color monitor), USB port .

With the puncture guiding function, line position can be adjusted
With gravel positioning, dynamic target area tracking function
Main power supply: AC220V±22V , 50/60Hz

×
