ALDR100E Electric Gynecology Chair Obstetric Delivery Table

ALDR multi position delivery bed is suitable for the new delivery mode under FAMC concept. Cooperate with the homely environmental design and plan, the bed makes the home—delivery successfully transfer to FCMC mode in hospital. The wide bed top, large up/down lifting distance, 90° swing out assistive table, ring—type lifting armrest combined with intelligent electric control system, all the great features enable the doctor to choose the most proper way (like use the assistive platform, not use the assistive platform, stand beside the bed) to help the lying—in women to give birth. There are also all kinds of delivery positions for lying—in women to choose from, like erect position, supine position, seat position, lateral position, squatting position, crawl position and the alike. It is the priority choice of an ALDR room.

ALDR100E Hospital Furniture Electric Gynecology Obstetric Delivery Table.jpg

Specification

Basic size

Table top dimension   Length:2040 mm

                   Width:1000mm

Overall length: 2150mm    Overall width: 1200mm

             Bed height:  Min. 590mm ~ Max.960mm

             Overall weight bearing of table top:   225kg

Functions

Back section turning up: 70°

Back section turning down: 10°

Seat section turning up: 20°

Seat section turning down: 0°

Assist platform

Assist platform lifting distance: 160mm

Assist platform weight bearing: 80kg

Assist platform swing out: 90°

Portal frame

Removable

Manual adjust angle

Electrical adjust extension of frame

Guard rail installation position

Two side of middle of back section

Up and down movement

Guard rail with control panel

Leg holder

Removable

Supporting mattress and supporting pole of leg holder can be adjusted and locked respectively

Leg holder is easy to lock and remove, and securely fixed.

Hidden type filth basin

Extension type

Swing out:  90°

Dimension of filth basin: 450mmx300mmx100mm

UPS system

Charging indicate

Auxiliary power supply reminder

Efficient and reliable charging circuit

Antifouling cover

Electric wheel lock-up and release system

×
